    Customized Automotive Injection Mould , 60 HRC Plastic Injection Molding

    Ask Lasest Price
    Brand Name : ERBIWA
    Model Number : EW230209
    Certification : ISO9001:2015
    Price : negotiable
    Payment Terms : T/T
    Supply Ability : 200 pcs
    Delivery Time : 30~45 days
    • Product Details
    • Company Profile

    Customized Automotive Injection Mould , 60 HRC Plastic Injection Molding

    Customized Automotive Injection Plastic Mold High Quality Plastic injection Molding


    Company NameERBIWA Mould Industrial CO., LTD.
    ManufacturingTool and Mold Making
    ApplicationPlastic Mold, Silicone Mold, Die Casting Tool and Sheet Metal Stamping Tool, etc.
    Design SoftwareUG, ProE, AutoCAD, Solidworks, etc.
    Raw MaterialP20, NAK80, H13, 8407, 2344, 718H, S316H, SKD61, etc.
    Steel Hardness20~60 HRC
    Inspection ToolCMM, VMS, Caliper, High Gauge, Pin Gauge, Dial Indicator, Micrometer, Ruler, Tape, Tester, etc
    Mold BaseLKM, HASCO, DME, etc.
    Runner SystemCold runner system and Hot runner system
    Cavity NumberSingle-cavity or Multi-cavities
    (As per customer’s requirement and part structure.)
    Ejection TechniquesGas assisted, Pin ejection, Sleeve ejection, Bar ejection, Blade ejection, etc.
    Gate TypeSprue gate, Edge gate, Sub-gate, Pin gate, Cashew gate, Themal gate, Valve gate, etc.
    Heat TreatmentQuenching, Nitriding, Tempering, etc.
    Cooling SystemLiquid cooling or Beryllium bronze cooling, etc.
    Surface TreatmentHigh gloss, Matte, EDM, Texture, Hardening, Coating etc
    Mold LifeClass 101 – Life expectancy of +1,000,000 cycles.
    Class 102 – Life expectancy not to exceed 1,000,000 cycles
    Class 103 – Life expectancy under 500,000 cycles
    Class 104 – Life expectancy less than 100,000 cycles
    Class 105 – Life expectancy less than 500 cycles.
    EquipmentCNC Machining, EDM, Wire Cutting, Grinding, Lathe, Milling, Drilling, Tapping, Fitting, Polishing, etc
    Lead time3~6 weeks depends on complexity of the mold
    Place of ExportDongguan China



    Our Strength


    1. Professional ISO 9001: 2015 Certificated OEM And ODM Tooling Manufacturer.


    2. TS16949 Certificated Moulding Manufacturer.


    3. 3 Sets Of Doubble-Head EDM Machines To Improve The Working Accuracy And Efficiency.


    4. EROWA Clamping System.


    5. All Inquiries Will Be Quoted Within 24 Working Hours.


    6. Familiar With HASCO, DME, MISUMI Standards.
